| 主要技術參數 | TECHNICAL DATA | UNIT | YP12090 |
| 最大壓制力 | Max.Pressing Force | kN | 120000 |
| 最大頂出力 | Max.Ejecting Force | kN | 400 |
| 動梁最大行(xing)程 | Max.Plunger Stroke | mm | 220 |
| 動梁下平(ping)面與工作臺面最小間(jian)距 | Min.Distance between Press Plunger and Table | mm | 580 |
| 動(dong)梁(liang)下平面(mian)與工作(zuo)臺面(mian)最大(da)間距 | Max.Distance between Press Plunger and Table | mm | 800 |
| 左右立(li)柱間凈空 | Clearance between Columns | mm | 3030 |
| 動梁工(gong)作面前后寬(kuan)度 | Useful Width of Plunger | mm | 1400 |
| 工作臺面前后寬(kuan)度 | Width of Press Table | mm | 1620 |
| 最大填料(liao)深度 | Max.Filling Depth | mm | 80 |
| 空循環次(ci)數可達(da) | Working Cycles in idle Stroke | mm-1 | 14 |
| 周期中加(jia)壓次數 | Strokes Per Cycle | times | 2～5 |
| 主電(dian)機功率(lv) | Power of the Main Motor | kW | 220 |
| 系統裝油量 | System Oil Capacity | L | 3800 |
| 系統耗氣量 | Air Consumption | m3/h | 0.5 |
| 常溫水流量 | Water Consumption at 24℃ | m3/h | 45 |
| 主(zhu)機重量 | Weight of the Press Body | t | 340 |
